Maximum ratings

STCF01

6/16

4

Maximum ratings

Table 2.

Absolute maximum ratings

Note:

Absolute Maximum Ratings are those values beyond which damage to the device may occur.

Functional Operation under these conditions is not implied.

Table 3.

Thermal data

Symbol

Parameter

Value

Unit

DC Input Voltage to SGLGND

-0.3 to 6

V

Switch Voltage

-0.3 to 20

V

FB, SEL,

SHDN, LC, HC

Voltage Range

V

OVP

Over Voltage Protection

-0.3 to 20

V

ESD

Human Body Model

±2kV

500

mW

Operating Junction Temperature Range

-40 to 85

°C

Junction Temperature

-40 to 125

°C

Storage Temperature Range

-65 to 150

°C

Symbol

Parameter

Value

Unit

Thermal Resistance Junction-Ambient

30.9

°C/W

Thermal Resistance Junction-Case

2.96

°C/W
