ADN4600

Rev. 0 | Page 27 of 27

Addr

(Hex)

Name

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

Default

0xD1

TX2 Output

Level Control 1

TX2 CTL

SRC

TX2_OLEV1[6:0]

0x40

0xD2

TX2 Output

Level Control 0

TX2_OLEV0[6:0]

0x40

0xD3

TX2 Squelch

Control

SQUELCHb[3:0]

DISABLEb[3:0]

0xFF

0xD9

TX3 Output

Level Control 1

TX3 CTL

SRC

TX3_OLEV1[6:0]

0x40

0xDA

TX3 Output

Level Control 0

TX3_OLEV0[6:0]

0x40

0xDB

TX3 Squelch

Control

SQUELCHb[3:0]

DISABLEb[3:0]

0xFF

0xE1

TX7 Output

Level Control 1

TX7 CTL

SRC

TX7_OLEV1[6:0]

0x40

0xE2

TX7 Output

Level Control 0

TX7_OLEV0[6:0]

0x40

0xE3

TX7 Squelch

Control

SQUELCHb[3:0]

DISABLEb[3:0]

0xFF

0xE9

TX6 Output

Level Control 1

TX6 CTL

SRC

TX6_OLEV1[6:0]

0x40

0xEA

TX6 Output

Level Control 0

TX6_OLEV0[6:0]

0x40

0xEB

TX6 Squelch

Control

SQUELCHb[3:0]

DISABLEb[3:0]

0xFF

0xF1

TX5 Output

Level Control 1

TX5 CTL

SRC

TX5_OLEV1[6:0]

0x40

0xF2

TX5 Output

Level Control 0

TX5_OLEV0[6:0]

0x40

0xF3

TX5 Squelch

Control

SQUELCHb[3:0]

DISABLEb[3:0]

0xFF

0xF9

TX4 Output

Level Control 1

TX4 CTL

SRC

TX4_OLEV1[6:0]

0x40

0xFA

TX4 Output

Level Control 0

TX4_OLEV0[6:0]

0x40

0xFB

TX4 Squelch

Control

SQUELCHb[3:0]

DISABLEb[3:0]

0xFF
