ADG526A/ADG527A

Rev. C | Page 7 of 20

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

Table 3.

Parameter

Rating

VDD to VSS

44 V

VDD to GND

25 V

VSS to GND

−25 V

Analog Inputs1

Voltage at Sx or Dx Pins

VSS − 2 V to VDD + 2 V

or 20 mA, whichever

occurs first

Continuous Current, Sx or Dx Pins

20 mA

Pulsed Current, Sx or Dx Pins

1 ms Duration, 10% Duty Cycle

40 mA

Digital Inputs1

Voltage at A, EN, WR, RS

VSS

− 4 V to VDD + 4 V

or 20 mA, whichever

occurs first

Power Dissipation (Any Package)

Up to 75°C

470 mW

Derates Above 75°C

6 mW/°C

Operating Temperature Range

Commercial (K Version)

−40°C to +85°C

Industrial (B Version)

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 10 sec)

300°C

1 Overvoltage at A, EN, WR, RS, Sx, or Dx pins are clamped by diodes. Limit

current to the maximum rating in

Table 3

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
