APM32E103CEU6-R datasheet(45/79 Pages) GEEHY

45 / 79 page

www.g eeh y.co m

Pag e 44

5.7.3.

Power consumption in sleep mode

Table 28 Power Consumption in Sleep Mode when the Program is Executed in Flash

Parameter

Conditions

fHCLK

Typical value (1)

Maximum value (1)

TA=25

℃，VDD=3.3V

TA=105

℃，VDD=3.6V

IDDA

(μA)

IDD(mA）

IDDA

(μA)

IDD(mA)

Power

consumption

in sleep mode

HSECLK bypass (2) , enabling all

peripherals

96 MHz

218.32

14.26

254.68

15.10

72MHz

152.47

9.76

180.70

10.58

48MHz

121.43

7.47

145.37

8.33

36MHz

98.48

5.80

119.78

6.79

24MHz

121.32

4.11

145.35

5.03

16MHz

91.28

2.94

112.16

3.97

8MHz

17.84

1.70

25.92

2.69

HSECLK bypass (2) , turning off all

peripherals

96 MHz

217.98

3.23

254.24

4.08

72MHz

152.21

2.35

180.39

3.29

48MHz

121.22

1.92

146.02

2.87

36MHz

98.38

1.59

119.88

2.58

24MHz

121.23

1.27

145.50

2.28

16MHz

91.20

1.05

112.22

2.04

8MHz

17.81

0.78

25.89

1.75

HSICLK (2) , enabling all

peripherals

64MHz

237.16

9.60

265.57

9.76

48MHz

206.68

6.92

232.79

7.61

36MHz

184.45

5.30

209.44

5.83

24MHz

163.15

3.65

187.49

4.21

16MHz

177.10

2.53

201.95

3.10

8MHz

102.66

1.32

122.81

1.93

HSICLK (2) , turning off all

peripherals

64MHz

237.18

1.90

266.22

2.52

48MHz

206.62

1.48

233.01

2.10

36MHz

184.34

1.17

209.43

1.79

24MHz

163.05

0.84

187.62

1.50

16MHz

177.13

0.62

202.01

1.27

8MHz

102.67

0.35

122.81

1.02
