RGC3A60..65 bảng dữ liệu(PDF) 9 Page - Carlo Gavazzi Holding AG |
|
|
|||||||||||||||||||||||||||||
RGC3A60..65 bảng dữ liệu(HTML) 9 Page - Carlo Gavazzi Holding AG |
|
|
9 / 41 page  9 Carlo Gavazzi Ltd. RGC2, RGC3 RGC2, RGC3 DS ENG 05/10/20 RG..D.. RG..A.. RG..D..D.. RG..D..A.. RG..A..A.. Control voltage range, UC (A1, A2) 5 - 32 VDC 20-275 VAC, 24 (-10%) -190 VDC 5 - 32 VDC 20-275 VAC Pick-up voltage 4.8 VDC 20 VAC/DC 4.8 VDC 20 VAC Drop-out voltage 1.0 VDC 5 VAC/DC 1.0 VDC 5 VAC Maximum reverse voltage 32 VDC - 32 VDC - Maximum response time 0.5 cycle + 500 μs @ 24 VDC 2 cycles @ 230 VAC/110 VDC 1 cycle + 500 μs @ 24 VDC 5 cycles @ 230 VAC Input current @ 40°C See diagrams below Inputs 115 VAC 230 VAC 400 VAC 480 VAC 600 VAC RGC2..10 ½ HP / 0.37 kW 1 HP / 1.1 kW 2 HP / 1.5 kW 3 HP / 2.2 kW 3 HP / 3 kW RGC2..25 1½ HP / 1.1 kW 3 HP / 3.0 kW 5 HP / 5.5 kW 7½ HP / 5.5 kW 10 HP / 9.0 kW RGC2..40 3 HP / 1.5 kW 5 HP / 4.0 kW 10 HP / 7.5 kW 10 HP / 9.0 kW 15 HP / 11.0 kW RGC2..75 5 HP / 3.0 kW 10 HP / 7.5 kW 15 HP / 11.0 kW 20 HP / 15.0 kW 25 HP / 22.0 kW RGC3..10 ½ HP / 0.37 kW 1 HP / 1.1 kW 2 HP / 1.5 kW 3 HP / 2.2 kW 3 HP / 3 kW RGC3..20 1 HP / 0.75 kW 3 HP / 2.2 kW 5 HP / 4.0 kW 7½ HP / 5.5 kW 10 HP / 7.5 kW RGC3..25 2 HP / 1.1 kW 3 HP / 2.2 kW 7½ HP / 4.0 kW 10 HP / 5.5 kW 10 HP / 7.5 kW RGC3..30 2 HP / 1.5 kW 5 HP / 3.0 kW 10 HP / 5.5 kW 10 HP / 7.5 kW 15 HP / 11.0 kW RGC3..40 2 HP / 1.5 kW 5 HP / 4.0 kW 10 HP / 7.5 kW 10 HP / 9.0 kW 15 HP / 11.0 kW RGC3..48 3 HP / 3.0 kW 10 HP / 5.5 kW 15 HP / 11.0 kW 20 HP / 15.0 kW 25 HP / 20.0 kW RGC3..65 3 HP / 3.0 kW 10 HP / 5.5 kW 15 HP / 11.0 kW 20 HP / 15.0 kW 25 HP / 20.0 kW Motor Ratings: HP (UL508) / kW (EN/IEC 60947-4-2) @ 40°C Input current vs input voltage RG..D RG..A 0.50mA 2.50mA 4.50mA 6.50mA 8.50mA 10.50mA 12.50mA 5V 6V 8V 10V 12V 14V 16V 18V 20V 22V 24V 26V 28V 30V 32V Input current vs Input voltage RG..D..D.., RG..D..A.. 0.00mA 1.00mA 2.00mA 3.00mA 4.00mA 5.00mA 20V 60V 90V 110V 150V 200V 230V 275V Input current vs Input voltage RG..A..A.. RG..D..D.. RG..D..A.. Input current vs Input voltage Input current vs Input voltage Input current vs Input voltage Input current vs Input voltage |
|
