Carlo Gavazzi Ltd.

RGC2, RGC3

RGC2, RGC3 DS ENG

05/10/20

Enter the code entering the corresponding option instead of

. Refer to selection guide section for valid part numbers.

Order code

RGC3A

Code

Option Description

Comments

Solid State Relay (RG)

With integrated heatsink

3-pole switching

Switching mode: zero cross

Rated voltage: 42-242 VAC, 800 Vp

Rated voltage: 42-660 VAC, 1200 Vp

90 - 660 VAC for RGC..M

Control voltage: 5-32 VDC

Control voltage: 20-275 VAC, 24-190 VDC

AC control range for RGC..A..A..

limited to 20-275 VAC only

Rated current

Not available with monitoring option

Rated current

Not available with monitoring option

Rated current

Screw connection for control terminals

Box clamp connection for control terminals

For RGC..M, RGC..F

Screw connection for power terminals

For RGC..10, RGC..20, RGC..25

Box clamp connection for power terminals

For RGC..30, RGC..40, RGC..75

Contactor configuration

External supply: 24 VDC

For RGC..F or RGC..M only

External supply: 90-250 VAC

For RGC..F or RGC..M only

Integrated fan with over temperature protection (OTP) and EMR alarm output For RGC..65

Monitoring for mains loss, load loss, SSR short circuit, open circuit

and over-temperature with EMR alarm output and auxiliary output

RGC..M is suitable only for

resistive loads

Panel mount version

Code

Option Description

Comments

Solid State Relay (RG)

With integrated heatsink

3-pole switching

Switching mode: zero cross

Rated voltage: 42-660 VAC, 1200 Vp

90 - 660 VAC for RGC..M

Control voltage: 5-32 VDC

Control voltage: 20-275 VAC, 24-190 VDC

AC control range for RGC..A..A..

limited to 20-275 VAC only

Rated current

Screw connection for control terminals

Box clamp connection for control terminals

Applicable to RGC..M

Box clamp connection for power terminals

Contactor configuration

External supply: 24 VDC

For RGC..M only

External supply: 90-250 VAC

For RGC..M only

Monitoring for mains loss, load loss, SSR short circuit, open circuit

and over-temperature with EMR alarm output and auxiliary output

RGC..M is suitable only for

resistive loads

DIN rail mount version
