background image
AP1184
4A ULTRA LOW DROPOUT POSITIVE ADJUSTABLE OR
FIXED-MODE REGULATOR
AP1184 Rev. 2
4 of 11
MAY 2007
www.diodes.com
© Diodes Incorporated
Electrical Characteristics ( Under Operating Conditions )
Unless otherwise specified, these specifications apply over, Cin = 1uF, Cout = 10uF, and Tj = 0 to 150
oC. Typical value refer to TA = 25oC.
Vout = Vsense.
Sym.
Parameter
Test Condition
Min. Typ. Max. Unit
VREF Reference Voltage
AP1184-Adj
IO =10mA, TA = 25
oC, (Vin-Vout) = 0.7V,
Vctrl = VIN+1V
1.225 1.250 1.275
V
Line Regulation
AP1184-XXX
IO = 10mA, VOUT+0.7V<VIN<12V, TA = 25
oC
Vctrl = VIN+1V
0.2
%
AP1184-1.5
IOUT = 10mA, TA = 25
oC, 2.2VφVINφ12V
Vctrl = VIN+1V
1.470 1.500 1.530
V
AP1184-1.8
IOUT = 10mA, TA = 25
oC, 2.5VφVINφ12V
Vctrl = VIN+1V
1.764 1.800 1.836
V
AP1184-2.5
IOUT = 10mA, TA = 25
oC, 3.2VφVINφ12V
Vctrl = VIN+1V
2.450 2.500 2.550
V
AP1184-3.3
IOUT = 10mA, TA = 25
oC, 4.0VφVINφ12V
Vctrl = VIN+1V
3.235 3.300 3.365
V
Vout Output Voltage
AP1184-5.0
IOUT = 10mA, TA = 25
oC, 5.7VφVINφ12V
Vctrl = VIN+1V
4.900 5.000 5.100
V
AP1184-Adj
0mA<Io<4A, TA= 25
oC
(VIN - VOUT) =2V ,Vctrl = VIN + 1V
1
%
AP1184-1.5
VIN = 3V, 0mA<Io<4A, TA = 25
oC
Vctrl = 4V
12
15
mV
AP1184-1.8
VIN = 3.3V, 0mA<Io<4A, TA = 25
oC
Vctrl = 4.3V
15
18
mV
AP1184-2.5
VIN = 4V, 0mA<Io<4A, TA = 25
oC
Vctrl = 5V
20
25
mV
AP1184-3.3
VIN = 5V, 0mA<Io<4A, TA = 25
oC
Vctrl = 6V
26
33
mV
Load
Regulation
AP1184-5.0
VIN = 8V, 0mA<Io<4A, TA = 25
oC
Vctrl = 9V
40
50
mV
Dropout Voltage
(Vctrl –Vout)
Vadj = 0V for all conditions below.
Vin = 2.05V, Io = 1.5A
Vin = 2.05V, Io = 3A
Vin = 2.05V, Io = 4A
1.10
1.15
1.18
1.25
V
Dropout Voltage
(Vin – Vout)
Vadj = 0V for all conditions below.
Vctrl = 2.75V, Io = 1.5A
Vctrl = 2.75V, Io = 3A
Vctrl =2.75V, Io =4A
0.26
0.50
0.70
0.38
0.60
0.85
V
Current Limit
Vctrl = 2.75V, Vin = 2.05V, ΔVo = 100mV, Vadj = 0V
4.2
A
Minimum Load
Current
Vctrl = 5V, Vin = 3.3V, Vadj = 0V
5
10
mA
Thermal Regulation 30mS Pulse
0.01
0.02
%/W
Ripple Rejection
Vctrl = 5V, Vin = 5V, Io = 4A, Vadj = 0V, Tj = 25, Vripple =1Vpp
at 120Hz
60
70
dB
Control Pin Current
Vadj = 0V for all conditions below.
Vctrl = 2.75V, Vin = 2.05V, Io = 1.5A
Vctrl = 2.75V, Vin = 2.05V, Io = 3A
Vctrl = 2.75V, Vin = 2.05V, Io = 4A
6
30
33
25
60
70
mA
