AP1184

4A ULTRA LOW DROPOUT POSITIVE ADJUSTABLE OR

FIXED-MODE REGULATOR

AP1184 Rev. 2

1 of 11

MAY 2007

www.diodes.com

•

0.85V maximum dropout voltage at 4A load current

•

Built-in Thermal shutdown

•

Output current limiting

•

Adjustable or fixed output voltage 1.5V, 1.8V, 2.5V,

3.3V, 5.0V

•

Fast transient response

•

Good noise rejection

•

Packages: TO220-5L and TO263-5L

•

Lead Free Finish/RoHS Compliant for Lead Free

products (Note 1)

AP1184 is a 4A regulator with extremely low dropout voltage.

This product is specifically designed to provide well regulated

supply for applications requiring 2.8V or lower voltages from 3.3V

ATX power supplies where high efficiency of the switch can be

achieved without the cost and complexity associated with

switching regulator. One such application is the new graphic

chipsets that requires anywhere from 2.4V to 2.7V supply.

AP1184 XX - XX X X

Package

Vout

K5 : TO263-5L

T5 : TO220-5L

Blank : Adj

15 = 1.5V

18 = 1.8V

25 = 2.5V

33 = 3.3V

50 = 5.0V

Packing

-U : Tube

-13 : Taping

Lead Free

L : Lead Free

Note:

1. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see EU Directive Annex Notes 5 and 7.

Note:

2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at

http://www.diodes.com/datasheets/ap02001.pdf.

Features

General Description

Ordering Information

Tube/Bulk

13” Tape and Reel

Device

Package

Code

Packaging

(Note 2)

Quantity

Part Number

Suffix

Quantity

Part Number

Suffix

AP1184K5

K5

TO263-5L

50

-U

800/Tape & Reel

-13

AP1184T5

T5

TO220-5L

50

-U

NA

NA

Lead-free

Lead-free
