127 / 236 page ![]() 6.9.5.2.3 CPSW3G RGMII Timing Table 6-35, Table 6-36, Table 6-37, Figure 6-31, Table 6-38, Table 6-39, and Figure 6-32 present timing conditions, timing requirements, and switching characteristics for CPSW3G RGMII. Table 6-35. CPSW3G RGMII Timing Conditions PARAMETER MIN MAX UNIT INPUT CONDITIONS SRI Input slew rate VDD(1) = 1.8V 1.44 5 V/ns VDD(1) = 3.3V 2.64 5 OUTPUT CONDITIONS CL Output load capacitance 2 20 pF PCB CONNECTIVITY REQUIREMENTS td(Trace Mismatch Delay) Propagation delay mismatch across all traces RGMII[x]_RXC, RGMII[x]_RD[3:0], RGMII[x]_RX_CTL 50 ps RGMII[x]_TXC, RGMII[x]_TD[3:0], RGMII[x]_TX_CTL 50 ps (1) VDD stands for corresponding power supply. For more information on the power supply name and the corresponding ball(s), see POWER column of the Pin Attributes table. www.ti.com TDA4VEN-Q1, TDA4AEN-Q1 SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024 Copyright © 2024 Texas Instruments Incorporated Submit Document Feedback 127 Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1 |
|
