6.9 Timing and Switching Characteristics

Note

The Timing Requirements and Switching Characteristics values may change following the silicon

characterization result.

Note

The default SLEWRATE settings in each pad configuration register must be used to ensure timings,

unless specific instructions are given otherwise.

6.9.1 Timing Parameters and Information

The timing parameter symbols used in Section 6.9, Timing and Switching Characteristics are created in

accordance with JEDEC Standard 100. To shorten the symbols, some pin names and other related terminologies

have been abbreviated in Table 6-3:

Table 6-3. Timing Parameters Subscripts

SYMBOL

PARAMETER

Cycle time (period)

Delay time

dis

Disable time

Enable time

Hold time

Setup time

START

Start bit

Transition time

Valid time

Pulse duration (width)

Unknown, changing, or don't care level

Fall time

High

Low

Rise time

Valid

Invalid

Active Edge

First Edge

Last Edge

High impedance

TDA4VEN-Q1, TDA4AEN-Q1

SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024

www.ti.com

Submit Document Feedback

Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1
