6.9.2 Power Supply Requirements

This section describes the power supply requirements to ensure proper device operation.

Note

All power balls must be supplied with the voltages specified in the Recommended Operating

Conditions section, unless otherwise specified in Signal Descriptions and Pin Connectivity

Requirements.

6.9.2.1 Power Supply Slew Rate Requirement

To maintain the safe operating range of the internal ESD protection devices, TI recommends limiting the

maximum slew rate of supplies to be less than 18mV/µs. For instance, as shown in Figure 6-2, TI recommends

having the supply ramp slew for a 1.8V supply of more than 100µs.

Figure 6-2 describes the Power Supply Slew Rate Requirement in the device.

slew rate < 18 mV/ s

slew > (supply value) / (18

)

supply value × 55.6 s/V

mV/ s

Supply value

SPRT740_ELCH_06

Figure 6-2. Power Supply Slew and Slew Rate

www.ti.com

TDA4VEN-Q1, TDA4AEN-Q1

SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024

Submit Document Feedback

Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1
