7 / 47 page  6.6 Electrical Characteristics - DC Specifications (continued) Maximum and minimum values are specified over the operating free-air temperature range and nominal supply voltages. Typical values are specified at TA = 25°C, 50% clock duty cycle, AVDD = IOVDD = 1.8 V, Internal 1.2 V reference, and –1-dBFS differential input, unless otherwise noted PARAMETER TEST CONDITIONS MIN TYP MAX UNIT DNL Differential nonlinearity -0.35 ±0.15 +0.35 LSB INL Integral nonlinearity -0.6 ±0.25 +0.6 LSB VOS_ERR Offset error -2.75 ±1 -2.75 LSB VOS_DRIFT Offset drift over temperature 0.001 LSB/ºC GAINERR Gain error Internal Reference ±0.8 %FSR GAINDRIFT Gain drift over temperature Internal Reference -102 ppm/ºC DC ACCURACY (125 MSPS) No missing codes 8 bits DNL Differential nonlinearity -0.35 ±0.15 +0.35 LSB INL Integral nonlinearity -0.6 ±0.25 +0.6 LSB VOS_ERR Offset error -2.75 ±1 2.75 LSB VOS_DRIFT Offset drift over temperature 0.001 LSB/ºC GAINERR Gain error Internal Reference ±0.8 %FSR GAINDRIFT Gain drift over temperature Internal Reference -102 ppm/ºC ADC ANALOG INPUT (INAP/M, INBP/M) FS Input full scale Differential 1.9 Vpp Single-ended 0.95 Vpp CIN Differential input Capacitance FIN = 100 kHz 7 pF VCM Input common mode voltage VOCM - 50mV 1.275 VOCM + 50mV V VOCM Output common mode voltage 1.25 V BW Analog Input Bandwidth (-3dB) 150 MHz CLOCK INPUT Input clock frequency ADC3908D125, ADC3908S125 5 125 MHz ADC3908D065, ADC3908S065 5 65 MHz ADC3908D025, ADC3908S025 5 25 MHz VIH High level input voltage AVDD - 0.3 1.8 Vpp VIL Low level input voltage 0 AVSS + 0.3 V CIN Input capacitance 0.5 pF Clock duty cycle 45 50 55 % DIGITAL INPUTS (RESET, PDN, M0, M1, M2) VIH High level input voltage 1.4 V VIL Low level input voltage 0.4 V IIH High level input current 90 150 uA IIL Low level input current -150 -90 uA CI Input capacitance 1.5 pF DIGITAL CMOS OUTPUTS (D0:D07) Output data rate per CMOS output pin 250 Mbps VOH High level output voltage ILOAD = -400 uA IOVDD - 0.1 IOVDD V VOL Low level output voltage ILOAD = 400 uA 0.1 V www.ti.com ADC3908D025, ADC3908D065, ADC3908D125 ADC3908S025, ADC3908S065, ADC3908S125 SBASAU9 – OCTOBER 2024 Copyright © 2024 Texas Instruments Incorporated Submit Document Feedback 7 Product Folder Links: ADC3908D025 ADC3908D065 ADC3908D125 ADC3908S025 ADC3908S065 ADC3908S125 |
|
