Data Sheet

LT3077

analog.com

Rev. 0

36 of 38

PART NUMBER

DESCRIPTION

COMMENTS

LT3072

Dual, Low Noise, 2.5A

Programmable Output, 80mV

Low Dropout Linear

Regulator

Dual, Independent 2.5A Outputs, Dropout Voltage: 80mV,

Low Output Noise: 12μVRMS (10Hz to 100kHz), Digitally

Programmable VOUT: 0.6V to 2.5V, Output Tolerance:

±1.25%/±1.5% Over-load, Line and Temperature, Analog

Output Margining: ±10% Range, 36-Lead 4mm × 7mm QFN

Package.

ADP1763

3A, Low VIN, Low Noise,

CMOS Linear Regulator

95mV Dropout, Fixed (0.9V to 1.5V) and Adjustable (0.5V to

1.5V) VOUT, VIN = 1.1V to 1.98V, 2µVRMS Noise (100Hz to 100kHz),

Programmable Soft Start,

Direct Parallelable, Stable with Ceramic Capacitors

(10µF minimum), AEC-Q100 qualified,

16-Lead 3mm x 3mm LFCSP Package.

ADP1765

5A, Low VIN, Low Noise,

CMOS Linear Regulator

59mV Dropout, Fixed (0.55V to 1.5V) and Adjustable (0.5V to

1.5V) VOUT, VIN = 1.1V to 1.98V, 2µVRMS Noise (100Hz to 100kHz),

Programmable Soft Start, Direct Parallelable, Stable with

Ceramic Capacitors (22µF minimum), 16-Lead 3mm x 3mm

LFCSP Package.

MAX38907

4A, High-Performance LDO

Linear Regulator

79mV Dropout, Digitally Programmable VOUT: 0.6V to 5V, VIN =

0.9V to 5.5V, Digital Margining: ±5%, Programmable Soft

Start, Reverse Current Protection, Active Discharge, 20-Lead

5mm x 5mm TQFN Package.

LT3041

20V, 1A, Ultra-low Noise,

Ultra-high PSRR Linear

Regulator with VIOC Control

1µVRMS Noise (10Hz to 100kHz), 8µVP-P Noise (0.1Hz to 10Hz),

80dB PSRR at 1MHz, VIN = 2.2V to 20V, VOUT = 0.2V to 15V,

310mV Dropout, Direct Parallelable, Programmable Current

Limit and Power Good, Stable with Low ESR Ceramic

Capacitors (2x 10µF Minimum), 14-Lead 4mm x 3mm DFN

Package.

LT3045

500mA, Ultra-low Noise and

Ultra-high PSRR LDO

0.8μVRMS Noise and 75dB PSRR at 1MHz, VIN = 1.8V to 20V,

260mV Dropout Voltage, 3mm × 3mm DFN and MSOP

Packages.

LT3042

200mA, Ultra-low Noise and

Ultra-high PSRR LDO

0.8μVRMS Noise and 79dB PSRR at 1MHz, VIN = 1.8V to 20V,

350mV Dropout Voltage, Programmable Current Limit and

Power Good, 3mm× 3mm DFN and MSOP Packages.

LT3083

3A, Parallelable, Low Noise,

Low Dropout Linear

Regulator

310mV Dropout Voltage (2-Supply Operation), Low Noise:

40μVRMS, VIN: 1.2V to 23V, VOUT: 0V to 22.6V, Current-Based

Reference with one Resistor VOUT Set, Directly Parallelable

(No Op Amp Required), Stable with Ceramic Capacitors;

TO-220, DD-PAK, TSSOP, 4mm × 4mm DFN-12 Packages.
