5 / 24 page

AD8337

Rev. B | Page 5 of 24

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Voltage

Supply Voltage (VPOS, VNEG)

±6 V

Input Voltage (INPx)

VPOS, VNEG

GAIN Voltage

VPOS, VNEG

Power Dissipation

(Exposed Pad Soldered to PC Board)

866 mW

Temperature

Operating Temperature Range

–40°C to +85°C

Storage Temperature Range

–65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Thermal Data—4-Layer JEDEC Board

No Air Flow Exposed Pad Soldered

to PC Board

θJA

75.4°C/W

θJB

47.5°C/W

θJC

17.9°C/W

ΨJT

2.2°C/W

ΨJB

46.2°C/W

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
