CC1000

SWRS048A

Page 42 of 55

PA_POW Register (0Bh)

NAME

Default

value

Active

Description

PA_POW[7:4]

PA_HIGHPOWER[3:0]

0000

Control of output power in high power array.

Should be 0000 in PD mode . See Table 11

page 32 for details.

PA_POW[3:0]

PA_LOWPOWER[3:0]

1111

Control of output power in low power array

Should be 0000 in PD mode. See Table 11

page 32 for details.

PLL Register (0Ch)

NAME

Default

value

Active

Description

PLL[7]

EXT_FILTER

1 : External loop filter

0 : Internal loop filter

1-to-0 transition samples F_COMP

comparator when BREAK_LOOP=1

(TEST3)

PLL[6:3]

REFDIV[3:0]

0010

Reference divider

0000 : Not allowed

0001 : Not allowed

0010 : Divide by 2

0011 : Divide by 3

…........

1111 : Divide by 15

PLL[2]

ALARM_DISABLE

0 : Alarm function enabled

1 : Alarm function disabled

PLL[1]

ALARM_H

Status bit for tuning voltage out of range

(too close to VDD)

PLL[0]

ALARM_L

Status bit for tuning voltage out of range

(too close to GND)
