DA9080

High Current, Highly Configurable System

PMIC with Four Bucks and One LDO

Datasheet

Revision 1.2

08-Feb-2022

CFR0011-120-00

9 of 51

Characteristics

5.1

Absolute Maximum Ratings

Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to

the device. These are stress ratings only, so functional operation of the device at these or any other

conditions beyond those indicated in the operational sections of the specification are not implied.

Exposure to Absolute Maximum Rating conditions for extended periods may affect device reliability.

Table 3: Absolute Maximum Ratings

Parameter

Description

Conditions

Min

Max

Unit

TSTG

Storage temperature

-60

150

°C

VSYS

System supply voltage

Referenced to AGND

-0.3

VPIN

All other pins

Referenced to AGND

-0.3

5.2

Electrostatic Discharge Ratings

Table 4: Electrostatic Discharge Ratings

Parameter

Description

Conditions

Value

Unit

VESD_HBM

Maximum ESD protection

Human body model (HBM)

All exposed pins

VESD_CDM

Maximum ESD protection

Charged device model (CDM)

0.5

5.3

Recommended Operating Conditions

Table 5: Recommended Operating Conditions

Parameter

Description

Conditions

Min

Typ

Max

Unit

Operating ambient

temperature

-40

°C

Operating junction

temperature

-40

125

°C

VSYS

Input supply voltage

5.5

VPIN

Voltage on all other pins

-0.3

VIN+0.
