STMPE812
Power modes
Doc ID 17732 Rev 3
13/51
5
Power modes
The STMPE812 operates in a 2 states: active and hibernate.
Active:
–
Whenever PEN-DOWN is detected, the device remains in active mode
–
Whenever PWM is active, the device remains in active mode
–
Whenever ADC is active, the device remains in ACTIVE MODE
Hibernate:
-PWM/ADC must be “off” (clock disable bit SET)
-Any GPIO input, with interrupt enabled cause a transition to “active” state, if an input
change is detected.
-Pen down even causes transition to “active” state if the touchscreen controller is enabled.
Table 5.
Power mode
Power mode
Active
Hibernate
Current consumption
280 µA (max)(1)
1.
At Vcc=1.8V, TCS running at 100sets of X/Y per second, MAV disabled.
1.0 µA (max.)
GPIO hotkey
Yes
Yes
Touchscreen
Yes
Yes
Interface (I2C)
Yes
Yes
Obsolete
Product(s)
- Obsolete
Product(s)
