40.3 Control Relays and Timers

EASY Intelligent Relays

Technical Data and Specifications

MFD-80, MFD-CP4, MFD-CP8

MFD I/O Modules

MFD-CP4 and CP8 Communication Modules

Note

1 Relay = 8A with resistive load, 3A with inductive load.

Transistor outputs = 0.5A/24 Vdc, maximum four outputs switchable in parallel.

Type

MFD-80…

MFD-CP4/CP8

Connection cables

Solid

—

0.2–4.0 mm2 (AWG 22-12)

Flexible

—

0.2–2.5 mm2 (AWG 22-12)

Degree of protection

IP 65

IP 20

RFI suppression

EN 55011, EN 55022 Class B, IEC 61000-6-1, 2, 3, 4

EN 55011, EN 55022 Class B, IEC 61000-6-1, 2, 3, 4

Ambient operating temperature

Clearly legible at –5 to 50°C

–25 to 55°C

Transport and storage temperature

–40 to 70°C

–40 to 70°C

Hazardous location

CSA Class I, Div. 2, Groups A, B, C, D; Temp. Code T3C

CSA Class I, Div. 2, Groups A, B, C, D; Temp. Code T3C

Type

MFD-AC-R16

MFD-R16

MFD-RA17

MFD-T16

MFD-TA17

Supply voltage

Supply via

MFD-CP8 module

Supply via

MFD-CP8 module

Supply via

MFD-CP8 module

Supply via

MFD-CP8 module

Supply via

MFD-CP8 module

Heat dissipation

0.5W

0.5W

0.5W

0.5W

0.5W

Continuous current outputs 1

8A

8A

8A

0.5A

0.5A

Short-circuit proof with

power factor 1

Line protection

B16, 600A

Line protection

B16, 600A

Line protection

B16, 600A

——

Short-circuit proof with

power factor 0.7…0.7

Line protection

B16, 600A

Line protection

B16, 600A

Line protection

B16, 600A

——

Connection cables

Solid

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

Flexible

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

Degree of protection

IP20

IP20

IP20

IP20

IP20

RFI suppression

EN 55011, EN 55022 Class B, IEC 61000-6-1,2,3,4

Ambient operating temperature

–25 to 55°C

–25 to 55°C

–25 to 55°C

–25 to 55°C

–25 to 55°C

Transport and storage temperature

–40 to 70°C

–40 to 70°C

–40 to 70°C

–40 to 70°C

–40 to 70°C

Mounting

Snap fitted to

MFD-CP8 module

Snap fitted to

MFD-CP8 module

Snap fitted to

MFD-CP8 module

Snap fitted to

MFD-CP8 module

Snap fitted to

MFD-CP8 module

Type

MFD-80…

MFD-CP4-…

MFD-CP8…

MFD-AC-CP8…

Supply voltage

Supply from -CP

24 Vdc

24 Vdc

100–240 Vac

Heat dissipation

3W

1.5W

3W

8 VA

Mounting

Front mounting in 2 x 22.5 mm

Standard drill holes

Snap fitted to MFD-80

Snap fitted to MFD-80 or on top-hat rail to DIN 50022, 35 mm or screw

Mounting with ZB4-101-GF1 fixing brackets
