40.3 Control Relays and Timers

EASY Intelligent Relays

Technical Data and Specifications

EASY700/800/MFD I/O Expansion Modules

Type

EASY202-RE

EASY618-AC-RE

EASY618-DC-RE

EASY620-DC-TE

EASY200-EASY

Supply voltage

—

100 – 240 Vac

24 Vac

24 Vac

—

Heat dissipation

1W

10 VA

4W

4W

1W

Continuous current outputs 1

8A

8A

8A

0.5A

—

Short-circuit proof with

power factor 1

Line protection

B16, 600A

Line protection

B16, 600A

Line protection

B16, 600A

Line protection

B16, 600A

—

Short-circuit proof with

power factor 0.7…0.7

Line protection

B16, 900A

Line protection

B16, 900A

Line protection

B16, 900A

Line protection

B16, 900A

—

Connection cables

Solid

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

0.2–4.0 mm2 (AWG 22-12)

Flexible

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

0.2–2.5 mm2 (AWG 22-12)

Degree of protection

IP20

IP20

IP20

IP20

IP20

RFI suppression

EN 55011, EN 55022 Class B, IEC 61000-6-1,2,3,4

Ambient operating temperature

–25° to 55ºC

–25° to 55ºC

–25° to 55ºC

–25° to 55ºC

–25° to 55ºC

Transport and storage temperature

–40° to 70ºC

–40° to 70ºC

–40° to 70ºC

–40° to 70ºC

–40° to 70ºC

Certification, standards

EN 50178, IEC/EN 60947, UL, CSA

Mounting

On top-hat rail to DIN 50022, 35 mm or screw mounting with ZB4-101-GF1 fixing brackets
