STA320

5.9 Channel Configuration Registers(Addresses 0E-10h

5.9.1 )

5.9.2

5.9.3

5.9.4 Tone Control Bypass

Tone control(bass/treble) can be bypassed on a per channel basis for channels 1 and 2.

CxTCB:

0 - Perform Tone Control on Channel X - normal operation

1 - Bypass Tone Control on Channel X

5.9.5 EQ Bypass

EQ control can be bypassed on a per channel basis for channels 1 and 2. If EQ control is bypassed on a

given channel the prescale and all filters (high-pass, biquads, de-emphasis, bass, treble in any combina-

tion) are bypassed for that channel.

CxEQBP:

0 - Perform EQ on Channel X - normal operation

1 - Bypass EQ on Channel X

5.9.6 Volume Bypass

Each channel contains an individual channel volume bypass. If a particular channel has volume bypassed

via the CxVBP = 1 register then only the channel volume setting for that particular channel affects the vol-

ume setting, the master volume setting will not affect that channel.

5.9.7 Binary Output Enable Registers

Each individual channel output can be set to output a binary PWM stream. In this mode output A of a

channel will be considered the positive output and output B is negative inverse.

CxBO:

0 - DDX tri-state output - normal operation

1 - Binary OutputLimiter Select

Limiter Selection can be made on a per-channel basis according to the channel limiter select bits.

D7

D6

D5

D4

D3

D2

D1

D0

C1OM1

C1OM0

C1LS1

C1LS0

C1BO

C1VPB

C1EQBP

C1TCB

000000

00

D7

D6

D5

D4

D3

D2

D1

D0

C2OM1

C2OM0

C2LS1

C2LS0

C2BO

C2VPB

C2EQBP

C2TCB

000000

00

D7

D6

D5

D4

D3

D2

D1

D0

C3OM1

C3OM0

C3LS1

C3LS0

C2BO

C3VPB

100000
