Package information

In order to meet environmental requirements, ST offers these devices in different grades of ECOPACK packages,

depending on their level of environmental compliance. ECOPACK specifications, grade definitions and product

status are available at: www.st.com. ECOPACK is an ST trademark.

9.1

[Package name] package information

Figure 6. TSSOP-20 package outline

Table 8. TSSOP-20 package mechanical data

Symbol

Milimeters

Inches(1)

Min.

Typ.

Max.

Min

Typ

Max

1.2

0.047

0.05

0.15

0.002

0.004

0.006

0.8

1.05

0.031

0.039

0.041

0.19

0.30

0.007

0.09

0.20

0.004

6.4

6.5

6.6

0.252

0.256

0.260

6.2

6.4

6.6

0.244

0.252

0.260

4.3

4.4

4.48

0.169

0.173

0.176

0.65 BSC

0.0256 BSC

0°

8°

0°

8°

0.45

0.60

0.75

0.018

0.024

0.030

1. Values in inches are converted from mm and rounded to 4 decimal digits.

LEOAD128

Package information

DS13668 - Rev 2

page 12/20
