ADL8142S

OUTLINE DIMENSIONS

©2022 Analog Devices, Inc. All rights reserved. Trademarks and

registered trademarks are the property of their respective owners.

One Analog Way, Wilmington, MA 01887-2356, U.S.A.

Rev. 0 | 8 of 8

Figure 3. 8-Lead Lead Frame Chip Scale Package [LFCSP]

2 mm × 2 mm Body and 0.85 mm Package Height

(CP-8-30)

Dimensions shown in millimeters

ORDERING GUIDE

Model1

Temperature Range

Package Description

Packing Quantity

Package Option

ADL8142ACPZN-CSL

−40°C to +85°C

8-Lead LFCSP, 2 mm × 2 mm × 0.85

Reel, 500

CP-8-30

ADL8142ACPZN-R7-CSL

−40°C to +85°C

8-Lead LFCSP, 2 mm × 2 mm × 0.85

Reel, 500

CP-8-30
