ADP1052
Data Sheet
Rev. B | Page 110 of 113
Table 199. Register 0xFEA6—First Flag ID
Bits
Bit Name/Function
R/W
Description
[7:4]
Previous first flag ID
R
These bits return the flag fault ID of the flag that caused the previous shutdown of the power
supply. This previous shutdown occurred before the shutdown caused by the fault identified
in Bits[3:0].
Bit 3
Bit 2
Bit 1
Bit 0
First Flag
0
0
0
0
No flag.
0
0
0
1
IIN_OC_FAST_FAULT.
0
0
1
0
IOUT_OC_FAULT.
0
0
1
1
CS3_OC_FAULT.
0
1
0
0
VOUT_OV_FAULT.
0
1
0
1
VOUT_UV_FAULT.
0
1
1
0
VIN_UV_FAULT.
0
1
1
1
FLAGIN.
1
0
0
0
SR_RC_FAULT.
1
0
0
1
OT_FAULT.
1
0
1
0
Reserved.
1
0
1
1
Reserved.
1
1
0
0
Reserved.
1
1
0
1
Reserved.
1
1
1
0
Reserved.
1
1
1
1
Reserved.
[3:0]
Current first flag ID
R
These bits return the flag fault ID of the fault that caused the shutdown of the power supply.
Bit 3
Bit 2
Bit 1
Bit 0
First Flag
0
0
0
0
No flag.
0
0
0
1
IIN_OC_FAST_FAULT.
0
0
1
0
IOUT_OC_FAULT.
0
0
1
1
CS3_OC_FAULT.
0
1
0
0
VOUT_OV_FAULT.
0
1
0
1
VOUT_UV_FAULT.
0
1
1
0
VIN_UV_FAULT
0
1
1
1
FLAGIN.
1
0
0
0
SR_RC_FAULT.
1
0
0
1
OT_FAULT.
1
0
1
0
Reserved.
1
0
1
1
Reserved.
1
1
0
0
Reserved.
1
1
0
1
Reserved.
1
1
1
0
Reserved.
1
1
1
1
Reserved.
