EXTENDED CONTROL REGISTERS

Two extended control registers are provided to supply controls and status information for the extended

features offered by the DS1689/DS1693. These are designated as extended control registers A and B and

are located in register bank 1, locations 04AH and 04BH, respectively. The functions of the bits within

these registers are described as follows.

Extended Control Register 4A

MSB

LSB

BIT 7

BIT 6

BIT 5

BIT 4

BIT 3

BIT 2

BIT 1

BIT 0

VRT2

INCR

*

*

PAB

RF

WF

KF

operation.

Bit 7: VRT2. This status bit gives the condition of the auxiliary battery. It is set to a logic 1 condition

battery should be replaced.

Bit 6: INCR (Increment in Progress Status). This bit is set to 1 when an increment to the time/date

registers is in progress and the alarm checks are being made. INCR is set to 1 at 122

µs before the update

cycle starts and is cleared to 0 at the end of each update cycle.

Bit 4: PAB (Power Active Bar Control). When this bit is 0, the

PWR pin is in the active-low state. The

user can write this bit to logic 1 or logic 0. If either [WF and WIE = 1] or [KF and KSE = 1], the PAB bit

is cleared to 0.

Bit 2: RF (RAM Clear Flag). This bit is set to logic 1 when a high-to-low transition occurs on the

RCLR

input if RCE = 1. The RF bit is cleared by writing it to logic 0. This bit can also be written to logic 1 to

force an interrupt condition.

Bit 1: WF (Wake-Up Alarm Flag). This bit is set to 1 when a wake-up alarm condition occurs or when

the user writes it to 1. WF is cleared by writing it to 0.

Bit 0: KF (Kickstart Flag). This bit is set to 1 when a kickstart condition occurs or when the user writes

it to 1. This bit is cleared by writing it to logic 0.
