US210AD

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 5

www.unisonic.com.tw



ABSOLUTE MAXIMUM RATING

over operating free-air temperature range unless otherwise noted (Note)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

-0.3 ~ 6

V

Enable Input Voltage

-0.3 ~ 6

V

SET Voltage

-0.3 ~ 6

V

Output Voltage

-0.3 ~ 6

V

Output Current

Internally Limited

A

Junction Temperature

+150

°C

Storage Temperature

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

°C/W



RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

MIN

TYP

MAX

UNIT

Supply Voltage

2.7

5.5

V

Enable Voltage

5.5

V

Continuous Output Current, OUT

1.0

A

Operating Virtual Junction Temperature

-40

+125

°C
