Configuration

• SMA Male Connector 1

• SMA Male Connector 2

• 50 Ohms

• Right Angle Body Geometry

Features

• Max VSWR of 1.35:1 up to 27 GHz

• Gold over Nickel Plated Beryllium Copper Contact

• Contact Plating per MIL-G-45204

Applications

• General Purpose Test

.

Description

Pasternack’s PE9642 SMA male to SMA male right angle adapter is part of our full line of RF components available for same-

day shipping. The SMA connector mates mechanically with commercially available 3.5mm and 2.92mm (K) connectors. Our

SMA to SMA adapter has a male to male gender configuration built of durable stainless steel. PE9642 SMA male to SMA male

adapter operates to 27 GHz. The Pasternack RF adapter provides good VSWR of 1.35:1 maximum. This low profile right angle

SMA adapter allows for easier connections in tight spaces.

RF adapters are often used to enable connections between two connector types that would otherwise not mate. Certain

adapter configurations can also be used to protect connectors on expensive equipment where the number of connect/

disconnect cycles is high. An RF, microwave or millimeter wave adapter is connected to the equipment, and the commonly

changed connection is made with the adapter which can be easily replaced when it wears out after high usage; such adapters

are referred to as connector savers. Pasternack also offers bulkhead, panel mount, hermetically sealed, reverse polarity, and

isolated ground adapter varieties to serve all of your RF, microwave and millimeter wave needs.

Electrical Specifications

Description

Minimum

Typical

Maximum

Units

Frequency Range

DC

27

GHz

VSWR

1.35:1

Insertion Loss

0.26

dB

. .

Electrical Specification Notes:

Values at 25°C, sea level.

Insertion Loss (dB) = 0.05*sqrt(fGHz).

Mechanical Specifications

Size

Length

0.7 in [17.78 mm]

Width

0.312 in [7.92 mm]

Height

0.67 in [17.02 mm]

Weight

0.02 lbs [9.07 g]

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: SMA Male to SMA Male Right Angle Adapter PE9642

PE9642 REV 1.1

SMA Male to SMA Male Right Angle Adapter

PE9642

RF Adapters Technical Data Sheet
