1. Introduction

The MIMO communication system has been one of the most promising technologies, well suited

for high data rate communication. A MIMO (Multiple-Input-Multiple-Output) system use at least

two antenna structures and is more advantageous than single-input single-output (SISO) in an

aspect of increasing channel capacity and reducing transmitting power. MIMO antennas should

have compact structure, high radiation efficiency, low envelope correlation, and high isolation

between the signal ports.

In small structures (antennas spaced closely), the application of MIMO technology has been

restricted by high degree of coupling and spatial correlation between antenna elements due to

the limited available space. The isolation between antennas become critical as it can deteriorate

the system performance and decreases channel capacity.

The Hercules MA510 MIMO antenna is low profile, heavy-duty, fully IP67 waterproof external

M2M antenna for use, transportation and remote monitoring applications. This unique

omnidirectional antenna provide high efficiency and high isolation between antennas elements

in a heavy-duty low profile compact structure, delivering powerful MIMO antenna technology for

Wi-Fi 802.11n and emerging 802.11ac.

The antenna screws down permanently onto a roof or metal panel and can be pole or wall-

mounted. The two antenna elements are vertically polarized.

For industries such as remote monitoring, smart meter systems, construction equipment, public

safety at only 29mm high, the Hercules MA510 MIMO antenna provides an unobtrusive, robust,

rugged antenna that is durable even in extreme environments. The antenna housing is

completely waterproof to IP67, and also to IP69K, which means it is waterproof against high

pressure water jets used in industrial environments for cleaning.

Also available in black.
