M93C86-x M93C76-x M93C66-x M93C56-x M93C46-x

Description

34

Figure 2. 8-pin package connections (top view)

1.

See Section 11: Package information for package dimensions, and how to identify pin-1.

2.

DU = Don't Use. The DU (do not use) pin does not contribute to the normal operation of the device. It is

reserved for use by STMicroelectronics during test sequences. The pin may be left unconnected or may be
