3. Absolute Maximum Ratings

Stresses greater than those listed as absolute maximum ratings in Table 2 could cause permanent damage to the device. These are stress

ratings only, and functional operation of the device at these or any other conditions above those indicated in the operational sections of this

specification is not implied. Exposure to absolute maximum rating conditions for extended periods might affect reliability.

Table 2.

Absolute Maximum Ratings

Pins[a]

Rating[b]

Units

AC1[c], AC2[c], COMM1, COMM2

-0.3 to 20

V

EN

̅̅̅̅

-0.3 to 28

V

SINK, VRECT

-0.3 to 24

V

DEN, ILIM, RPPG, RPPO, VDD18, VOSET

-0.3 to 2

V

ALIGNX, ALIGNY, INT

̅̅̅̅, SCL, SDA, TS, VDD5V

-0.3 to 6

V

BST1, BST2

-0.3 to AC1+6, AC2+6

V

OUT

-0.3 to 14.4

V

Maximum Current on SINK

1

A

Maximum RMS Current on COMM1, COMM2

500

mA

Maximum RMS Current from AC1, AC2

2

A

[a] Absolute maximum ratings are not provided for reserved pins (RSV1, RSV2, RSV3, RSV4, RSV5, and DEN). These pins

are not used in the application.

[b] All voltages are referred to ground unless otherwise noted.

[c] During synchronous rectifier dead time, the voltage on the AC1 and AC2 pins is developed by current across the power

FET’s body diodes, and it might be lower than -0.3 V. This is a normal behavior and does not negatively impact the

functionality or reliability of the product.

Table 3.

ESD Information

Test Model

Pins

Ratings

Units

HBM

All pins except RSV2 and RSV3

2

kV

RSV2, RSV3 pins

1

kV

CDM

All pins

500

V
