FEATURES

19.5 x 10.2 x 7.6 mm (0.77”x 0.4”x 0.3”)

PRODUCT OVERVIEW

The MAU300 series is a range of 2W DC/DC converters in a small SIP Package featuring an I/O-isolation of 1000VDC. An excellent efficiency allows an

operating temperature range of –40°C to +85°C.

These converters offer an economical solution for many applications where a voltage has to be isolated i.e for noise reduction, ground loop elimination,

digital interfaces or for board level power distribution with isolated voltages.

Model Selection Guide

Output Current

Input Current

Efficiency

(typ.)

Input

Voltage

(Range)

Output

Voltage

Max.

Min.

@Max. Load @No Load

Load

Regulation

Max. capacitive

Load

@Max. Load

Model

Number

VDC

VDC

mA

mA

mA(typ.)

mA(typ.)

% (max.)

µF

%

MAU301

3.3

500

10

452

11

73

MAU302

5

400

8

526

11

76

MAU303

12

165

3

495

7

80

MAU304

15

133

2.5

499

7

470

80

MAU305

±5

±200

±4

519

10

77

MAU306

±12

±83

±1.5

504

7

79

MAU307

5

(4.5 ~ 5.5)

±15

±66

±1

501

60

7

390#

79

MAU311

3.3

500

10

185

8

74

MAU312

5

400

8

212

8

78

MAU313

12

165

3

200

5

82

MAU314

15

133

2.5

200

5

470

83

MAU315

±5

±200

±4

210

8

79

MAU316

±12

±83

±1.5

201

5

82

MAU317

12

(10.8 ~ 13.2)

±15

±66

±1

200

30

5

390#

82

MAU321

3.3

500

10

92

8

74

MAU322

5

400

8

108

8

77

MAU323

12

165

3

101

5

81

MAU324

15

133

2.5

101

5

470

82

MAU325

±5

±200

±4

105

8

79

MAU326

±12

±83

±1.5

102

5

81

MAU327

24

(21.6 ~ 26.4)

±15

±66

±1

100

15

5

390#

82

# For each output

Input Specifications

Parameter

Model

Min.

Typ.

Max.

Unit

5V Input Models

4.5

5

5.5

12V Input Models

10.8

12

13.2

Input Voltage Range

24V Input Models

21.6

24

26.4

5V Input Models

-0.7

---

9

12V Input Models

-0.7

---

18

Input Surge Voltage (1 sec. max.)

24V Input Models

-0.7

---

30

VDC

Reverse Polarity Input Current

---

---

0.3

A

Internal Filter Type

Pi Filter

Internal Power Dissipation

All Models

---

---

650

mW
