background image
Data Sheet
ADL5506
Rev. A | Page 7 of 23
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
Rating
Supply Voltage, VPOS
5.5 V
RF Input Power, RFIN1, 2
15 dBm
Equivalent Voltage, Sine Wave Input
1.25 V rms
Internal Power Dissipation
75 mW
θJA (WLCSP)
260°C/W
Maximum Junction Temperature
145°C
Operating Temperature Range
−40°C to +85°C
Storage Temperature Range
−65°C to +150°C
1 Driven from a 50 Ω source.
2 Under 50 Ω input matched condition.
Stresses at or above those listed under Absolute Maximum
Ratings may cause permanent damage to the product. This is a
stress rating only; functional operation of the product at these
or any other conditions above those indicated in the operational
section of this specification is not implied. Operation beyond
the maximum operating conditions for extended periods may
affect product reliability.
ESD CAUTION
