background image
Copyright © 2014 Future Technology Devices International Limited
28
Document No.: FT_000648
FT121 ENHANCED USB DEVICE CONTROLLER WITH SPI SLAVE IC
Datasheet Version 1.2
Clearance No.: FTDI#
312
Error Code
Result
0010
PID unknown
0011
Unexpected packet
0100
Token CRC error
0101
Data CRC error
0110
Time out error
0111
Reserved
1000
Unexpected EOP
1001
Packet NAKed
1010
Sent stall
1011
Buffer overflow
1101
Bit stuff error
1111
Wrong DATA PID
Table 6.15 Transaction error code
6.3.4 Read Endpoint Status
Command
: 80-85h (80-8Fh for Enhanced Mode)
Data
: Read 1 byte
Bit
Symbol
Reset
Description
1-0
Reserved
0b’00
Reserved
2
Setup packet
0
0: indicate not a setup packet
1: indicate last received packet has a SETUP token
4-3
Reserved
0b’xx
Reserved
5
Buffer 0 Full
0
0: buffer 0 is not filled up
1: buffer 0 is filled up
6
Buffer 1 Full
0
0: buffer 1 is not filled up
1: buffer 1 is filled up
