1 / 1 page

4-7

BENG3G

BEEG3G

L

O

Cy

A

D

Cy

L'

N'

G'

Cx

L

SW

L

I

L

N

E

G

N

R

R: OPTION

I

N

G

E

N

L

SW

R

Cx

N'

L'

G'

Cy

L

O

D

A

L

Lg

3GA ONLY

UNIT:

INCH

mm

BENG3G

1.563 0.004

R0.14

R3.5

39.7 0.1

1.22 0.004

R2.5(8X)

R0.098(8X)

31.0 0.1

SUGGESTED MOUNTING CUTOUT

(MOUNTING FROM FRONT)

Suggested thickness of mounting

panel is from 0.04(1.0) to 0.63(1.6) inch(mm)

of mounting cutout

1.713REF.

43.5REF.

2.146REF.

54.5REF.

2.264REF.

57.5REF.

SUGGESTED MOUNTING CUTOUT

(MOUNTING FROM FRONT)

1.713REF.

43.5REF.

2.146REF.

54.5REF.

2.264REF.

57.5REF.

R3.5

M3

1.535 0.004

R0.14

39.0 0.1

BEEG3G

R0.098(8X)

R2.5(8X)

1.417

36.0

SERIES

SWITCH CONNECTOR FILTERS

1. Maximum leakage current each

line-to-ground @ 115VAC 60Hz: 0.25mA

@ 250VAC 50Hz: 0.45mA

2. Hipot rating (one minute)

line-to-ground: 2250VDC

line-to-line: 1450VDC

3. Operating frequency: 50/60Hz

4. Rated voltage: 115/250VAC

SPECIFICATIONS

1. Designed as a general purpose filter with a switch

effective EMI suppression for both common and

differential mode noise.

2. With optional resistor and Y capacitance 3300pF/1000pF

3. Bleader resistor is added with suffix "-R".

4. Switch electrical lifetime : 10,000 cycles.

Maximum inrush current : 50A.

INTRODUCTIONS

A: with ground choke

PART NO.

Cx (uF) L (mH) Cy (pF) R (

) Lg (mH)

03BEEG3G/NG3G/-R

2.4

03BEEG3GA/NG3GA/-R

06BEEG3G/NG3G/-R

0.8

0.1

2200

1M

0.12

06BEEG3GA/NG3GA/-R

10BEEG3G/NG3G/-R

0.3

10BEEG3GA/NG3GA/-R

COMPONENTS

CURRENT

FREQUENCY-MHz

RATING

.15

.50

1.0

5.0

10

30

3A (G) (A)

20

30

35

COMMON MODE (L-G) IN 50 OHM SYSTEM

DIFFERENTIAL MODE (L-L) IN 50 OHM SYSTEM

6A (G) (A)

10

20

25

35

40

35

10A (G) (A)

5

10

20

30

35

3A (G) (A)

4

10

20

35

40

6A (G) (A)

4

10

35

40

10A (G) (A)

5

10

20

30

35

MINIMUM INSERTION LOSS IN dB

MECHANICAL CONSTRUCTION

ELECTRICAL SCHEMATIC

D

V

E
