1 / 2 page

Production specification

SURFACE MOUNT SCHOTTKY

BARRIER RECTIFIERS

D8PS20--D8PS100

Document Number: T2B409AA

www.gmicroelec.com

1

FEATURES

Super long operating life

Plastic package has Underwriters Laboratory

Flammability Classification 94V-0

MECHANICAL DATA

Case: TO-277B molded plastic body

Mounting position: ANY

Maximum Ratings(@TA = 25°C unless otherwise specified)

Characteristic

Symbol

D8

PS20

D8

PS30

D8

PS40

D8

PS45

D8

PS50

D8

PS60

D8

PS90

D8

PS100

UNITS

Maximum recurrent peak reverse voltage

VRRM

20

30

40

45

50

60

90

100

V

Maximum RMS voltage

VRMS

14

21

28

31.5

35

42

63

70

V

Maximum DC blocking voltage

VDC

20

30

40

45

50

60

90

100

V

Maximum average forward rectified current at

TL=90℃

IF(AV)

8.0

A

Peak forward surge current

8.3ms single half sine -wave

IFSM

275

A

Thermal Characteristics

Characteristic

Symbol

D8

PS20

D8

PS30

D8

PS40

D8

PS45

D8

PS50

D8

PS60

D8

PS90

D8

PS100

UNITS

Operating temperature range

TJ

- 55 ---- +125

- 55 ---- +150

℃

Storage temperature range

TSTG

- 55 ---- +150

℃

Electrical Characteristics (@TA = 25°C unless otherwise specified)

Characteristic

Symbol

D8

PS20

D8

PS30

D8

PS40

D8

PS45

D8

PS50

D8

PS60

D8

PS90

D8

PS100

UNITS

Maximum instantaneous forward voltage

at IFM=8.0A

VF

0.55

0.70

0.85

V

Maximum DC reverse current

TJ=25℃

at rated DC blocking voltage

TJ=100℃

IR

0.2

20

m A

Pb

Lead-free
