Trigger

C1 DC

Stop

-150mV

Edge

Negative

Timebase

-1.04 s

Roll

1.00s/div

500kS

50 kS/s

100%

60%

30%

Figure 1.7 demonstrates a typical switch dimming waveform. Channel 1 (blue) is the supply voltage. Channel 4

(magenta) shows the output current at 100%, then 60%, and then 30%.

Figure 1.7

Switch Dimming Waveform (Dimming Mode 2)
