ADA4939-1/ADA4939-2

Data Sheet

Rev. A | Page 12 of 24

–60

–120

–110

–100

–90

–80

–70

100

FREQUENCY (MHz)

VOUT, dm =HD2, = 1V p-p

VOUT, dm =HD3, = 1V p-p

VOUT, dm =HD2, = 2V p-p

VOUT, dm =HD3, = 2V p-p

VS = ±1.65V

Figure 25. Harmonic Distortion vs. Frequency at Various Output Voltages

–30

–40

–50

–60

–70

–80

–90

–100

110

100

FREQUENCY (MHz)

RL, dm = 200Ω

Figure 26. PSRR vs. Frequency, RL = 200 Ω

–5

–50

–45

–40

–35

–30

–25

–20

–15

–10

100

FREQUENCY (MHz)

RL, dm = 200Ω

S11

S22

Figure 27. Return Loss (S11, S22) vs. Frequency

–30

–35

–40

–45

–50

–55

–60

–65

–70

110

100

FREQUENCY (MHz)

RL, dm = 200Ω

Figure 28. Output Balance vs. Frequency

–10

100

–350

–300

–250

–200

–150

–100

–50

0.01

10k

100

0.1

FREQUENCY (MHz)

GAIN

PHASE

Figure 29. Open-Loop Gain and Phase vs. Frequency

–8

–6

–4

–2

060

TIME (ns)

VIN × 3.16V

VOUT

Figure 30. Overdrive Recovery, G = 3.16
