Δ

TR : ±2%

Δ

V.S.S.: ±1%

Δ

TR : ±2%

IR

: 10M ohm min.

Δ

TR : ±1%

Δ

V.S.S.: ±1%

Δ

TR : ±1%

Δ

V.S.S.: ±1%

Δ

TR : ±3% or 3 ohm max., whichever is greater

Δ

V.S.S.: ±1%

Δ

TR : ±2%

Δ

V.S.S.: ±2%

Δ

TR : ±3%

Δ

V.S.S.: ±2%

Δ

TR : R≤100 kohm

±3% or 2 ohm max., whichever is greater

R>100 kohm

+0/-10% (50 cycles)

Temperature

Cycle

Humidity

Vibration (20G)

Shock (100G)

Temperature

Load Life

Low Temperature

Exposure

High Temperature

Exposure

Rotational Life

Δ

TR : Total Resistance Change

Δ

V.S.S.: Voltage Setting Stability

IR

: Insulation Resistance

Characteristics

PVG3.pdf

01/17

Specifications are subject to change without notice.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.

Users should verify actual device performance in their specific applications.

Part Numbering

PV G3 A 103 C01 R00

Product ID

PV = Trimming Potentiometer

Series

G3 = SMD Sealed 3 mm Square, Single-Turn

Pin Style

A = J-Hook

G = Gull-Wing

Total Resistance

Expressed by three figures.

The first and second figures are

significant digits; the third figure expresses

the number of zeros that follow.

Individual Specification

C01 = Standard Type

Packaging

R00 = Tape and Reel (1,000 pcs./7 ” reel)

Resistance

Resistance

(Ohms)

Code

10

100

20

200

50

500

100

101

200

201

500

501

1,000

102

2,000

202

5,000

502

10,000

103

20,000

203

50,000

503

100,000

104

200,000

204

500,000

504

1,000,000

105

2,000,000

205

Popular distribution values listed in boldface.

Special resistances available.
