Low Cost Semi-Precision

Power Wirewound Resistor

LAS Series

• 4222 South Staples Street • Corpus Christi Texas 78411 USA

Wire and Film Technologies Division

Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com

Physical Data

Dimensions (Inches (mm))

IRC

Type

A ±0.032

B (max)

C (max)

D (Lead Diameter)

E (Lead length Min)

LAS-1

0.348 (8.84)

0.110 (2.80)

0.407 (10.34)

0.020 (0.53)

1.475 (37.5)

LAS-3

0.491 (12.47)

0.149 (3.80)

0.550 (13.99)

0.032 (0.81)

1.35 (34.3)

Low Cost Semi-Precision

Power Wirewound Resistor

A

C

B

D

E

Hot Spot Temperature @ 25°C

0

40

80

120

160

200

Percent of 25°C Power

275

250

200

150

100

25

50

LAS3

LAS1

LAS1

Hot Spot Temperature @ 125°C

0

20

40

60

80

100

Percent of 125°C Power Rating

275

250

225

200

175

125

150

LAS3

LAS Series Issue October 2008 Sheet 2 of 3
