UNISONIC TECHNOLOGIES CO., LTD

SB3150

Preliminary

DIODE

www.unisonic.com.tw

1 of 3

QW-R202-063.a

3.0A SCHOTTKY BARRIER

RECTIFIER



DESCRIPTION

The UTC SB3150 is a 3.0A schottky barrier rectifier, it uses

UTC’s advanced technology to provide the customers with high

surge capability, high efficiency, high current capability and low

forward voltage drop, etc.

The UTC SB3150 is suitable for free wheeling and polarity

protection, etc.

 FEATURES

* High surge capability

* High efficiency

* High current capability

* Low power loss

* Low forward voltage drop



SYMBOL

SMB

+

-



ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

1

2

Packing

SB3150L-SMB-R

SB3150G-SMB-R

SMB

K

A

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode



MARKING

Date Code

Cathode Band for

uni-directional Only

UTC

SB3150

L: Lead Free

G: Halogen Free
