RB520S40

Preliminary

SCHOTTKY DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R202-061.a



PARAMETER

SYMBOL

RATINGS

UNIT

Peak Repetitive Reverse Voltage

40

V

Working Peak Reverse Voltage

40

V

DC Blocking Voltage

40

V

Forward Continuous Current

250

mA

Non-repetitive Peak Forward Surge Current (Note 3)

1.0

A

Junction Temperature

+125

°C

Storage Temperature

-55 ~ +125

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX UNIT

0.37

V

Forward Voltage Drop

0.60

V

1.00

μA

Reverse Leakage Current

5.00

μA

Total Capacitance

50

pF

Reverse Recovery Time

10

ns

Note: Pulse width ≤ 300μs, duty cycle ≤ 2%.
