SRB Series

Minimum Depth, Cost-eﬀective Shielded Power Inlet Filter (continued)

206

Dimensions are in inches and millimeters unless otherwise speciﬁed. Values in italics

are metric equivalents. Dimensions are shown for reference purposes only.

Speciﬁcations subject to change.

Corcom Product Guide

Catalog: 1654001

Issue Date: 06.2011

For email, phone or live chat, please go to

te.com/help

corcom.com

PC Board Layout

0.551

13.99

0.520

13.21

0.075

1.91 ∅

*±.015 [0.38]

.685*

17.40*

Recommended Panel Cutouts

Tolerances ± .005 [0.13] unless otherwise noted

.140

3.56

.12

3.05

.820

20.8

1.200

30.48

1.575

40.01

.140

3.56

.234

5.94

.900

22.9

1.200

30.48

1.575

40.01

Front Mount

Back Mount

Typ.

∅









0.815

20.70

Tolerance ±.002 [.050]

0.188

4.775

Max.

SRBS















SRB1, SRB2, SRBP & SRB8

Cover

Jacket

Flange

0.15

3.81

Panel

Thickness .039 [1.0] ± .005 [.127]

1.066

27.07

.722

18.34

.836

21.23

min.

max.

min.

± .005 [.127]

SRBX

Cover

Jacket

Flange

0.15

3.81

max.

1.05

26.67

1.15

29.21

min.

.741

18.82

± .005 [.127]

Panel

Thickness .039 [1.0] ± .005 [.127]

SRBY

SRBX8
