ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VIN

18V

Enable Voltage

VEN

+20

Junction Temperature

-40 ~ +125

°C

Storage Temperature

TSTG

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



OPERATING RATINGS (Note 1)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VIN

+2.25 ~ +16

Enable Voltage

VEN

+16

Maximum Power Dissipation

Note 2

Notes: 1. The device is not guaranteed to function outside its operating rating.

2. PD(max)=(TJ(max)-TA)+ θJA, where θJA -junction-to-ambient thermal resistance.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

SOP-8

°C/W

Junction to Case

HSOP-8

θJC

°C/W
