Series AM2D-RZ

2 Watt | DC-DC Converter

www.aimtec.com

Tel: +1 514 620 2722

Toll free: + 1 888 9 AIMTEC

(924 6832)

F 051e R12.C

3 of 6

North America only

Input Specifications

Parameters

Nominal

Typical

Maximum

Units

Voltage range

4.5-5.5

VDC

10.8-13.2

13.5-16.5

21.6-26.4

43.2-52.8

Filter

Capacitor

Absolute Maximum Rating

5 Vin

VDC

12 Vin

15 Vin

24 Vin

48 Vin

Peak Input Voltage time

100

No Load Input Current

Isolation Specifications

Parameters

Conditions

Typical

Maximum

Units

TestedI/O voltage

60sec

1000, 3000

VDC

Resistance

>1000

MOhm

Capacitance

Output Specifications

Parameters

Conditions

Typical

Maximum

Units

Voltage accuracy

±3

Short Circuit protection

Momentary (1sec)

Line voltage regulation

For 1.0% of Vin

1.2

% of Vin

Load voltage regulation

Load 10~100%

±5

Temperature coefficient

±0.02

%/oC

Ripple & Noise

20MHz Bandwidth

mVp-p

Minimum Load Current

% of Max

General Specifications

Parameters

Conditions

Typical

Maximum

Units

Switching frequency

100% load

KHz

Operating temperature

-40 to +85

Storage temperature

-40 to +125

Maximum case temperature

100

Cooling

Free Air Convection

Humidity

% RH

Case material

Plastic UL94V-0

Weight

2.8

Dimensions (L x W x H)

0.76 x 0.28 x 0.39 inch

19.50 x 7.20 x 10.00 mm

MTBF

>1.9 Mhrs (MIL-HDBK -217F, Ground Benign, t=+25oC)hours

Maximum soldering temperature

1.5mm from case for 10 sec

260

Safety Specifications

Parameters

Agency Approval

Standards

EN55022: 2006 + A1: 2007, Class B

EN55024: 1998 + A1: 2001 + A2:2003

IEC61000-4-2:2008

IEC61000-4-3: 2006 + A1: 2007

IEC61000-4-4, 2004

IEC61000-4-6: 2008

IEC61000-4-8: 1993 + A1:2000
