SAW FILTER

HDF110L

S3

www.shoulder.cn

Tel:0755-82916880

Fax:0755-82916881

E-mail:info@shoulder.cn

Page 3 of 8

1. SCOPE

This specification shall cover the characteristics of SAW filter F110L.

2. ELECTRICAL SPECIFICATION

DC Voltage VDC

10V

AC Voltage Vpp

10V50Hz/60Hz

Operation temperature

-40℃ to +85℃

Storage temperature

-45℃ to +85℃

RF Power Dissipation

0dBm

2.2Electronic Characteristics

型号

Part Number

HDF110L

中心频率(fo)(MHz)

Nominal Center Frequency

110

3dB 带宽

Bandwidth(from fo)(KHz)

+/-576min

阻带衰耗

Stop Band Attenuation

(from peak level)(dB)

1)fo-3×1.728MHz

2)fo-2×1.728MHz

3)fo+/-1.728MHz

4)fo+2×1.728MHz

5)fo+3×1.728MHz

50min

45min

30min

40min

40min

插入损耗(dB)

Insertion Loss(at minimum loss point)

4.5max

群延时波动(fo+/-576KHz)(μsce.)

Group Delay Deviation

0.7

输入/输出阻抗

Input/output Impedance

300Ω//1.2μH
