28 V Wide Maxi Family

Rev 2.8

vicorpower.com

Page 7 of 12

02/2016

800 927.9474

28 V Input

+IN

PC

PR

–IN

+OUT

+S

SC

–S

–OUT

C3*

4.7nF

C2*

4.7nF

For C1 – C5, keep leads and connections short.

C5*

4.7nF

C4*

4.7nF

F1*

C1*

0.2µF

Figure 1 — Basic module operation requires fusing, grounding, bypassing capacitors.

* See Maxi, Mini, Micro Design Guide.

BASIC MODULE OPERATION

Comprehensive Online Application Information

The Design Guide and Applications Manual includes:

• Application circuits

• Design requirements

• EMC considerations

• Current sharing in power arrays

• Thermal performance information

• Recommended soldering methods

• Accessory modules – filtering, rectification, front-ends

• Mounting options

...and more.

Also at vicorpower.com

• PowerBench online configurators

• Over 20 Application Notes

• Online calculators – thermal, trimming, hold-up

• PDF data sheets for ALL Vicor products

CLICK HERE TO VIEW

DESIGN GUIDE
