Component

Material and Finish

Pin Insulator

Synthetic resin

Shell

Zinc alloy / Trivalent chromate treatment over

zinc plating

Retaining Ring

Zinc alloy / Trivalent chromate treatment over

zinc plating

O-Ring

Synthetic rubber

Contact

Copper alloy / Gold plating

Component

Material and Finish

Front Insulator

Synthetic resin

Rear Insulator

Synthetic resin

O-Ring

Synthetic rubber

Coupling Nut

Zinc alloy / Trivalent chromate treatment over

zinc plating

Spring

Stainless steel

Assembly Nut

Synthetic resin

Endbell

Synthetic resin

Bushing

Synthetic rubber

Grand Nut

Synthetic resin

Fixation Pin

Copper alloy / Nickel plating

Flange

Zinc alloy / Chromium plating*

Clamp Saddle

Synthetic resin

Cross Recessed Head

Machine Screw With Captive

Washer

Stainless steel

Hexavalent Nut

Stainless steel

Contact

Copper alloy / Gold plating

JN2/W

■ Receptacle

■ Plug

Materials and Finishes

* Chromium plating: chromium plating (hexavalent chromium free) over nickel over copper
