1 / 2 page

VOLTAGE RANGE: 50 - 1000V

1 of 2

SINGLE PHASE SILICON BRIDGE RECTIFIER

KBPC3005-KBPC310

Dimensions in inches and (milimeters)

KBPC3

Characteristic

Symbol KBPC

3005

KBPC

301

KBPC

302

KBPC

304

KBPC

306

KBPC

308

KBPC

310

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

VR

50

100

200

400

600

800

1000

V

RMS Reverse Voltage

VR(RMS)

35

70

140

280

420

560

700

V

Average Rectified Output Current (Note 1) @TC = 50°C

IO

3.0

A

Non-Repetitive Peak Forward Surge Current 8.3ms

Single half sine-wave superimposed on rated load

(JEDEC Method)

IFSM

A

Forward Voltage per leg

@IF = 1.5A

VFM

1.1

V

Peak Reverse Current

@TA = 25°C

At Rated DC Blocking Voltage

@TA = 125°C

IR

5.0

500

µA

I2t Rating for Fusing (t<8.3ms) (Note 2)

I2t

A2s

Typical Junction Capacitance (Note 3)

Cj

pF

Typical Thermal Resistance per leg (Note 1)

R JC

°C/W

Operating and Storage Temperature Range

Tj, TSTG

-65 to +125

°C

Note: 1. Mounted on metal chassis.

2. Non-repetitive, for t > 1ms and < 8.3ms.

3. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.

50

10

25

10

www.sunmate.tw

Maximum Ratings and Electrical Characteristics T

A = 25

°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.

Features

!

Diffused Junction

!

High Current Capability

!

High Surge Current Capability

!

Mechanical Data

!

Terminals: Plated Leads Solderable per

MIL-STD-202, Method 208

!

Mounting Position: Through Hole for #6 Screw

!

Mounting Torque: 5.0 Inch-pounds Maximum

!

Marking: Type Number

High Case Dielectric Strength

Flammability Classification 94V-O

Plastic Material has Underwriters Laboratory

Ideal for Printed Circuit Board Application

Case: Molded Plastic

Weight: 3.8 grams (approx.)

Polarity: Marked on Body

CURRENT: 3.0 A
