CPC1961

Dimensions

mm

(inches)

User Direction of Feed

NOTES:

1. Dimensions carry tolerances of EIA Standard 481-2

2. Tape complies with all “Notes” for constant dimensions listed on page 5 of EIA-481-2

Embossment

Embossed Carrier

Top Cover

Tape Thickness

0.102 MAX.

(0.004 MAX.)

330.2 DIA.

(13.00 DIA.)

K

(0.165)

0

K =4.90

(0.193)

P=12.00

(0.472)

W=16.00

(0.63)

Bo=10.30

(0.406)

Ao=10.30

(0.406)

CPC1961GSTR Tape & Reel
