Package Style and Pinning (mm)

ECONOLINE

DC/DC-Converter

R0.25S/E

Series

12.75

6.70

7.00

2.54x3

10.70

11.10

RECOM

R0.25S-0505/E

1131

12

3

87

11.10

0.50

Footprint

2.54

1.20

1.80

12.00

4

6

5

Typical Characteristics

Tolerance Envelope

+10%

+5%

VNOM

+5%

-2%

-5%

10%

50%

100%

R0.25S-xx05/E

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

0

10

20

30

40

50

60

70

Efficiency/Load

Load %

3.305

0505

1205

80

90

100

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

-10

-5

0

5

10

15

20

25

Deviation/Load

Load %

3.305

0505

1205

UNIT: mm

TOL.: ± 0.25 mm

Pin Connections

Pin # Function for 5 Pins

Function for 8 Pins

1

–Vin

- Vin

2

+Vin

+Vin

4

-Vout

-Vout

5

+Vout

+Vout

3, 6, 7

NA

NC

8NC

NC

NC= No Connection

NA= No Available Electrical Connection

Notes

Note1:

Maximum capacitive load is defined as the capacitive load that will allow start up in under 1second without damage to the converter.

The product information and specifications are subject to change without prior notice. RECOM products are not authorized for use in safety-critical applications (such as life support) without RECOM’s explicit

written consent. A safety-critical application is defined as an application where a failure of a RECOM product may reasonably be expected to endanger or cause loss of life, inflict bodily harm or damage property. The buyer

shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized use of RECOM products in such safety-critical applications.

REV: 0/2015

E-13
