Cymbet Product Ordering Information

Cymbet, the Cymbet Logo, and EnerChip are Cymbet Corporation Trademarks

Disclaimer of Warranties; As Is

The information provided in this data sheet is provided “As Is” and Cymbet Corporation disclaims all representations or warranties of any

kind, express or implied, relating to this data sheet and the Cymbet EnerChip product described herein, including without limitation, the

implied warranties of merchantability, fitness for a particular purpose, non-infringement, title, or any warranties arising out of course of

dealing, course of performance, or usage of trade. Cymbet EnerChip products are not authorized for use in life critical applications. Users

shall confirm suitability of the Cymbet EnerChip product in any products or applications in which the Cymbet EnerChip product is adopted

for use and are solely responsible for all legal, regulatory, and safety-related requirements concerning their products and applications and

any use of the Cymbet EnerChip product described herein in any such product or applications.

EnerChip CC Part Number

Description

Notes

CBC3105-R4C

EnerChip CC 5µAh in 16-pin DFN

Shipped in Tube

CBC3105-R4C-TR1

CBC3105-R4C-TR5

EnerChip CC 5µAh in 16-pin DFN

Tape-and-Reel - 1000 pcs (TR1) or

5000 pcs (TR5) per reel

CBC3105-R4C-WP

EnerChip CC 5µAh in 16-pin DFN

Waffle Pack

CBC3112-D7C

EnerChip CC 12µAh in 20-pin D7

DFN Package

Shipped in Tube

CBC3112-D7C-TR1

CBC3112-D7C-TR5

EnerChip CC 12µAh in 20-pin D7

DFN Package

Tape-and-Reel - 1000 pcs (TR1) or

5000 pcs (TR5) per reel

CBC3112-D7C-WP

EnerChip CC 12µAh in 20-pin D7

DFN Package

Waffle Pack

CBC3150-D9C

EnerChip CC 50µAh in 20-pin D9

DFN Package

Shipped in Tube

CBC3150-D9C-TR1

CBC3150-D9C-TR5

EnerChip CC 50µAh in 20-pin D9

DFN Package

Tape-and-Reel - 1000 pcs (TR1) or

5000 pcs (TR5) per reel

CBC3150-D9C-WP

EnerChip CC 50µAh in 20-pin D9

DFN Package

Waffle Pack

U.S. Patent No. 8,044,508. Additional U.S. and Foreign Patents Pending
